Newport 818-IR-L-FC/DB Fiber Optic Detector,780-1800nm,10 mW
Manufacturer:
Newport
Model:
818-IR-L-FC/DB
Condition:
New
Availability:
4 pcs
Price:
$760.00
Qty:
Description:
Feature
Newport 818-IR-L-FC/DB Fiber Optic Detector, Ge, 780-1800nm, 10 mW, DB15
The 818-IR-L-FC/DB is a flexible fiber optic detector that can easily be converted to a free space detector simply by removing the 884-FC fiber optic adapter installed on it. It has a power range of -75 to 1.1 dBm in case of handheld meters; this range is higher for benchtop meters (-75 to 10 dBm). It is compatible with all the current Newport optical power meter models that have a DB15 interface. Please note that models 818-IR-L and 818-IR-L/DB are no longer available for purchase. Purchase 818-IR-L-FC/DB and remove the connector and/or the fiber adapter.
Technical Specs
Detector Type
Germanium Sensor
Detector Input
Fiber-Optic
Fiber-Optic Connector
FC/PC
Detector Material
Germanium
Spectral Range
780 - 1800 nm
Sensor Size
Ø3 mm
Minimum Measurable Power
20 pW
Maximum Measurable Power Benchtop Meter
10 mW
Maximum Measurable Power Handheld Meter
1.3 mW
Maximum Power Density
3 W/cm
2
Maximum Pulse Energy
5 nJ
Power Range
-75 to 10 dBm
Calibration Module
Removable DB15 Connector
Calibration Uncertainty
2% @ 780-1700nm
4% @ 1701-1800 nm
Linearity
±0.5 %
Uniformity
±2 %
Rise Time
≤2 µs
Connector Type
DB15
Cable Length
1.5 m
